Vilikh plywood
Vilikh shuttering Plywood
Vilikh Ply is designed to withstand rigors of construction work while maintaining a smooth & flawless finish. Builders and contractors are sure to appreciate the combination of durability & precision that Vilikh offer. Vilikh uses a premium 120 GSM film coating on both sides delivering exceptional protection against moisture , chemicals and abrasions.
Vilikh Ply is manufactured aligning multiple layers of phenolic resin-coated 100% hardwood veneers at right angles to each other and compressing them under high pressure ensuring a sturdy and resilient final product . The extra compression not only enhances nail and screw holding capacity but also contributes to the overall longevity and quality of the plywood. By using carefully selected quality veneer, Vilikh Ply sets a high standard for performance & reliability in the construction industry.
100% Weather Proof
Better Nail Holding
Wrap Resistant
No Core Gap
Boiling Water PRoof
Detailed Specs
It is being used widely in the construction of bridge , flyover , metro projects,
Ship building, water tanks, cooling tower, all high -rise buildings etc., which need
Maximum strength and security.
- Size : 2440mm X 1220mm
- Thickness : 9mm,12mm, 15mm, 18mm , 25mm & 30mm
Weight :
- 23 ,30 ,34, 36,38&42 KG in 12mm
- 38, 45, 52, 54, 56 & 60 KG in 19mm
Density : 0.65 to 1.20 gm/cm
Test :
1. Moisture content test: BIS CLAUSE : Cl-10.1.1 REQUIRED VALUE : 5 to 15 % RESULT :7.8 %
02. Glue Adhesion strength in dry
state:
a) Glue shear strength
i) Average failing load
ii) Average wood failure
b) Adhesion of plies
BIS CLAUSE : Cl-10.1.2 REQUIRED VALUE: Average value-1350 N (Min.),No requirement, Min. pass standard . RESULT
1802.50, Nil , Excellent
03 Water Resistance Te:st
a) Glue shear strength
i) Average failing load
ii) Average wood failure
b) Adhesion of plies
BIS CLAUSE: Cl-10.1.3, REQUIRED VALUE : Average value-1000 N, (Min.),
No requirement, Min. pass standard. RESULT: 1608.20,Nil,Pass
TEST:
4. Visual observation of surface layer after being subjected to 72 hr boiling . BIS CLAUSE: Cl-10.1.4, RESULT REQUIRED :No sign of softening, checking, cracking or deterioration on the surface layer. RESULT :Satisfactory
5. Resistance to mic-roro ganism
a) Edge of the specimen
b) Glue shear strength
i) Average failing load
ii) Average wood failure
c) Adhesion of plie
BIS CLAUSE :Cl-10.1.5 , REQUIRED VALUE : No sign of separation at the edge,
Average value-1000 N, (Min.),No requirement, Min. passstandard. RESULT:
Satisfactory ,1450.48, NILL ,PASS.
6. Tensile strength, N/mm²
a) Along the grain direction
b) Across the grain direction
c) Sum of tensile strength (a+b)
BIS CLAUSE: Cl-10.1.6, REQUIRED VALUE : 32.5 (Min.), 22.5 (Min.), 60.0 (Min.), RESULT: 50.08, 52.54, 102.62.
TEST
7. Static Bending Strength(in Dry)
A)Modules of Elasticity (N/mm²)
Along the grain direction
RESULT VALUE :
AVG. Ind. Value-7500(Min.)
Min. Ind. Value-6700(Min.)
RESULT: 8776.00, 7540.42
Across the grain direction
RESULT VALUE :
AVG. Ind. Value-4000(Min.)
Min. Ind. Value-3600(Min.)
RESULT: 5721.00, 4588.64
B)Modules of Rupture (N/mm²
Along the grain direction
RESULT VALUE :
AVG. Ind. Value-50(Min.)
Min. Ind. Value-40 (Min.)
RESULT:64.46, 52.44
Across the grain direction
RESULT VALUE :
AVG. Ind. Value
Min. Ind. Value-27 (Min.)
RESULT:51.24, 38.50
8. Wet Bending Strength
A)a) Modules of Elasticity (N/mm²)
Along the grain direction
RESULT VALUE :
AVG. Ind. Value
Min. Ind. Value
RESULT: 5720.00, 4701.00
Across the grain direction
RESULT VALUE :
AVG. Ind. Value
Min. Ind. Value
RESULT: 4250.60, 3200.00
B)Modules of Rupture (N/mm²
Along the grain direction
RESULT VALUE :
AVG. Ind. Value-25(Min.)
Min. Ind. Value-22 (Min.)
RESULT:40.1 ,37.8
Across the grain direction
RESULT VALUE :
AVG. Ind. Value-15 (Min.)
Min. Ind. Value-13(Min.)
RESULT:30.2, 29.4
9. Retention of preservative chemical, BIS CLAUSE: Cl-10.1.9, RESULT VALUE : 12 Kg/cm³(Min.) RESULT :13.42
